PERSEE A3F

Product Details:

Place of Origin:	Beijing, China
Brand Name:	Persee
Model Number:	A3F

Detail Information

Place of Origin:

Beijing, China

Brand Name:

Persee

Model Number:

A3F

Customized Support:

OEM

Warranty:

3 Years

Weight:

165kg

Optical System:

Grating 1800 Lines/mm

Gas System:

Three Kinds Of Gas System Available

Focal Length:

0.1,0.2,0.4,1.0,2.0nm

Size:

1100mmX535mmX540mm

Wavelength Range:

185 - 910nm

Trading Information

Minimum Order Quantity:

1 set

Price:

$16,000-23,000 / set

Product Description

The instrument is equipped with a flame atomiser only. The positioning of which is fully controlled by the embedded computer system and AA-Win Pro software. Three flame options are available to the user with the Air/Acetylene being the standard configuration. This flame can be used for nearly all standard elements while the N2O/Acetylene and the Air/LPG (Natural gas) are available as an option for the more demanding of elements. All three flame configurations offer coded burner for full safety protection.

Specifications:

Spectrometer System
Wavelength range	185-910nm
Light source	Hollow cathode lamp (HCL), Deuterium Arc lamp (D2)
Modulation	Square wave pulse
Modulation frequency	100hz self reversal (SR) background, 400hz Deuterium Arc (D2) background
Monochromator
Grating	1800 grooves/mm diffraction grating
Blazed wavelength	250nm
Focus	300nm
Bandwidth	0.1, 0.2, 0.4, 1.0, 2.0, 5.0nm
Scan mode	Automatic
Photometric type	Single beam
Wavelength accuracy	+0.15nm
Wavelength resolution	0.2nm+0.02nm
Wavelength reproducibility	<0.05nm
Baseline stability	0.005A/30min
Stray light	≤0.12%T(220nm NaI, 340nm NaNO2)
Background correction	Deuterium Arc (D2) 1.0Abs, Self Reversal (SR) 3.0Abs
Flame Analysis
Flame types	Air/Acetylene, Nitrous Oxide/Acetylene, Air/Propane (LPG)
Sensitivity (Cu)	2μg/ml Absorption >0.280Abs
Characteristic concentration	Cu<0.02μg/ml, Ba<0.15μg/ml (N2O/Acetylene)
Detection limit	Cu<0.004μg/ml
repeatability	Cu<0.7% (Air/Acetylene Flame) Ba<1.0% (Nitrous Oxide/Acetylene Flame)
Burner heads	Titanium alloy
Nebulizer	High efficiency glass, Acid proof available as an option
Pre-mix chamber	Corrosion resistant
Atomizer selection	Automatic changeover (A3FG),
Safety features	Burner identification, flame sensor, gas leak sensor, low gas pressure sensor, drain trap sensor, power loss protection
Data Processing
Operating program	AA Win Pro software
Analytical methods	Flame AA, Flame AE, Graphite Furnace, Hydride Generation
Readout Mode	Continuous, manual, peak height, peak area
calibrations	Multi-standard calibration, standard addition, interpolation
Data storage	Analytical results, instrument and measurement parameters, signal profile,calibration curve
Power Requirements
Main unit	220Vac 50/60hz 200W
Graphite power supply	220Vac 50/60hz instantaneous power 5KW current rating
Dimensions
Main unit	110x54x54cm 75kg
Graphite power supply	50x54x54cm 70kg

Standard Features

Embedded PC system built into the instrument as standard on all configurations. Pre-installed UV-Win Pro software, user manuals, cook book and Windows 7 professional operating system.
UV-Win Pro software provides full control of the instrument and autosampler with easy method change for each technique.
Automatic 8 Hollow Cathode lamp turret controlled and optimised by the AA-Win Pro software. Operating lamp current and warm-up lamp current can be individually controlled to eliminate drift commonly associated with lamp warming.
D2 lamp background correction system fitted as standard to all configurations. High energy D2 lamp and adjustable beam splitter mirror are optimised by the AA-Win pro software.
Self Reversal background correction system fitted as standard to all configurations. The high performance background system uses the same hollow cathode lamp as installed for the analysis. Minimum extra components are required and optical alignment is very simple. Self Reversal can be used for any element at any wavelength making it extremely versatile.
High precision minimal optics ensures maximum light throughput to the computer controlled Czerny-Turner monochromator.
A universal autosampler is available as an optional accessory which is conveniently mounted on the front of the AA500 instrument.
Absorption and Emission modes are standard features in the AA WinPro software as well as peak height, peak area, sequential and manual integration modes.

Flame Atomiser Features

The flame atomiser offers three flame options:
Air/acetylene is the standard configuration with the N2O/acetylene and Air/LPG as options.

Air/Acetylene

The Air/Acetylene flame uses a 100mm single slot burner for the standard configuration.
The high sensitivity (Cu 2ppm >0.280abs) is due to the efficiency of the fixed position glass nebuliser fitted as standard. An acid resistant replacement is available as an option.
The flame can be easily set from blue lean flame through stoichiometric to fuel rich by means of computer control.

N20/Acetylene

The N2O/Acetylene flame uses a 50mm single slot burner and is available as an optional extra.
This flame configuration is used to measure elements less prone to ionization such as: Aluminium, Tin, Titanium, Calcium, Vanadium and Molybdenum.
Switching from Air/Acetylene to N2O/Acetylene to Flame Off is fully controlled by the AAWinPro software.

Air/Propane (LPG)

This flame uses a 3 slot burner and with the low pressure requirement it is also much safer to operate.
Due to the low temperature of the flame it is ideal for analysing alkali metals such as: Potassium, Sodium and Lithium, especially when used in the emission mode.
Some remote areas of the world have difficulty obtaining Acetylene gas of a high enough purity to operate the flame correctly, LPG can give a real alternative and offer comparable results for most elements throughout the wavelength range.

Safety Features

Pressure monitoring for all gases.
Burner Identification
Flame sensor
Drain Trap level Sensor
Gas Leak Detector
Over Pressure in Premix.
Safety Cut off Switch.
